A detailed series of maps of one of the world's largest railway networks, with accurate track alignments, providing up-to-date information on the tracks, stations, yards, etc.
72 pages of full colour maps, of 1 : 1,500,000 scale, referenced by a locator map.
Accurate alignments and locations.
Approximately 11,000 locations, including existing and closed stations, sidings, control points etc indexed and with their respective station codes. Divisional and zonal headquarters identified.
Most closed lines and stations depicted.
A majority of sidings and industrial lines shown.
Tracks show gauge, whether single or double, electrification, etc, colour coded according to the divisions they fall under.
Most works in progress including new lines, gauge conversions, electrification, including those under survey, etc.
All loco sheds (electric, diesel and steam), EMU/DMU car-sheds, important freight yards, goods sheds and container terminals marked.
With approx. 30 detailed inset maps (mostly 5x scale) of complex areas.
Glossary of name/spelling changes.
Single spread At-a-Glance map of entire system, showing the jurisdiction of the various zones.
What's New over the First Edition
Completely updated.
Highly accurate alignments and locations and corrected junctional directions.
More detailed indication of rivers and water bodies, roads and airports.
Most sidings of over 2 kms length marked. Most non-IR tracks shown.
Full colour printing, where line colour denotes respective division.
Many more detailed inset maps of complex areas.
102 pages, weight 200gm approx. Size 235mm x 178mm. Softbound, laminated cover, pages open flat to make reference easy.
For more details of the atlas, see Samit Roychoudhury own web site at http://www.indianrailstuff.com/gira2.html
Post and Packing UK: £1.25, EU: £3.60, Int'l - Airmail: £6.30
